- Self Loading Concrete Mixer
Model: SM-1.8
Discharge Capacity: 1.8m³/batch
Max. Drive Speed: 30km/h
Rated Power: 78kw
Model: SM-2.6
Discharge Capacity: 2.6m³/batch
Max. Drive Speed: 30km/h
Rated Power: 78kw
Model: SM-3.5
Discharge Capacity: 3.5m³/batch
Max. Drive Speed: 30km/h
Rated Power: 85kw
Model: SM-4.0
Discharge Capacity: 4.0m³/batch
Max. Drive Speed: 35km/h
Rated Power: 91kw
Model: SM-5.5
Discharge Capacity: 5.5m³/batch
Max. Drive Speed: 35km/h
Rated Power: 92kw
Self Loading Concrete Mixer — 1.8 to 5.5 m³/Batch, One Operator, On-Site Concrete Production
SMAT self loading mixers combine loading, weighing, mixing, transporting and discharging in one machine. No batching plant required. No external loader. Ready for road construction, real estate projects and remote job sites.
Hot Sale
SMAT Best Sale Self Loading Mixer
Self Loading Mixer SM-3.5
The SM-3.5 is SMAT's hottest selling self loading mixer truck. It meets the needs of most construction and road projects.
- Model: SM-3.5
- Discharge Capacity: 3.5m³/batch
- Max. Drive Speed: 30km/h
- Rated Power: 85kw
Self Loading Mixer Truck SM-4.0
The SM-4.0 is the mixer truck with a capacity of 4m³ per batch. It is SMAT's hottest selling model in the world. It is great for both real estate projects and road construction.
- Model: SM-4.0
- Discharge Capacity: 4.0m³/batch
- Max. Drive Speed: 35km/h
- Rated Power: 91kw
Choose the Right Capacity for Your Project
Five batch sizes from 1.8 to 5.5 m³. Not sure which one fits your daily output? Tell us your project and we will recommend it — free.
| Model | Discharge Capacity | Drive Speed | Rated Power | Best For |
|---|---|---|---|---|
| SM-1.8 | 1.8 m³/batch | 30 km/h | 78 kW | Small residential, rural roads |
| SM-2.6 | 2.6 m³/batch | 30 km/h | 78 kW | Village construction, small projects |
| SM-3.5★ Most popular | 3.5 m³/batch | 30 km/h | 85 kW | Road & building projects Real output ≈ 14–18 m³/hour |
| SM-4.0 | 4.0 m³/batch | 35 km/h | 91 kW | Real estate, medium-scale road construction |
| SM-5.5 | 5.5 m³/batch | 35 km/h | 92 kW | Large infrastructure, high daily output |
Not sure which model? Chat with our engineer — tell us your daily concrete demand and site conditions.
Four Things Every Other Supplier Will Not Put in Writing
Anyone can claim “high quality” and “good service”. Here is what 36 years of shipping mixers into 30+ countries actually means for your project.
Not “long history” — but knowing every failure mode before it reaches you
SMAT was established in 1988. Every mixer we ship carries the lessons from 36+ years of field data across 30+ countries. When a hydraulic hose failed in Laos in 2016, that fix went into the next production batch — and into this machine.
Not “good after-sales” — but an engineer flying to your job site
SMAT provides engineers for on-site installation guidance, commissioning and operator training. English and Chinese language support, so nothing gets lost between our engineer and your site crew.
Foundation-Free Concrete Batching Plant
25–240 m³/h
Self-supporting steel structure that removes the need for a poured concrete foundation — ideal for fast deployment and leased land.
- No foundation civil works required
- Faster installation, lower site cost
- SICOMA MAO mixer on 120/180 models
Dry Mix & Drum Mixer Plant
Custom capacity
Two lighter configurations for specific jobs: dry batching where no mixer is needed, and drum-mixer plants for smaller or remote works.
- Dry plant — no mixer, aggregate proportioning only
- Drum mixer plant — portable, low maintenance
- Capacity built to your requirement
Will It Work on Your Site?
Three of the most common site conditions our customers build on — and which model we usually recommend for each.
Road projects far from the nearest batching plant
When the plant is two hours away, every ready-mix delivery is a gamble on traffic and slump. The mixer drives to the aggregate pile, loads, mixes and discharges directly at the pour location — you only pay for one machine travelling.
Most chosen: SM-3.5 and SM-4.0
Tight sites where a mixer truck cannot turn around
The compact structure and 4-wheel steering let the mixer manoeuvre where a full-size transit truck simply cannot enter. Multi-story building construction gets a continuous concrete supply without blocking the access road.
Most chosen: SM-4.0 for multi-story works
No batching plant, no grid power, no paved road
Village housing and rural roads rarely justify the cost of installing a batching plant. The mixer is self-contained: it loads from an aggregate pile on site and discharges right where the concrete is needed, even on unpaved ground.
Most chosen: SM-1.8 and SM-2.6
What SMAT Would Do After Making Oder
Compared to traditional concrete batching plants, self-loading concrete mixers require no other equipment and less labor. It is a versatile and effective solution for small and medium-sized projects.
Quality Service Before Shipping
SMAT takes every order seriously. Every step of the process is checked by special person. Every important component is pre-tested before shipment, especially the mixer machine. It also ensures that free spare parts are given to the customer to avoid any possible accidents.
01
Packing and shipping
SMAT has nearly 30 years of export experience. The self loading mixer manufactured by us have been exported to different countries. The Concrete Batching Plant will be packed and loaded in our factory, and then be shipped to our clients safe and sound.
02
Technical Service
SMAT provides engineers with on-site installation guidance, commissioning, and training services. SMAT engineers have rich experience in mechanical, electrical, and civil engineering. Proficiency in English and Chinese, the common languages, ensures smooth communication with operators on site.
03
Service
- China SMAT is in Zhengzhou City. Make sure timely and rapid response to customer needs.
- Engineers team are always available for on-site installation guidance, commissioning, and training services.
- SMAT provides regular visiting to clients sites, thus can promptly correct improper operations.
- Adequate stock of original spare parts to ensure the smooth operation of the project.
- Free customized product appearance color and Logo, provide ODM support.
- VIP groups are created for customers. If you have any questions, feel free to give feedback.
- 7*24 hours online free consulting service, including quotation, 2-3 sets of program design, AutoCAD & 3D drawings, and site planning.
